| Product Code | Description | Product Size | Grade | Composition | Capacity |
| 765163-1EA | Lithium nickel manganese cobalt oxide | 5 in. à 10 in., 16 μm | Battery grade | Loading, â¥80% | 150 mAh/g(minimum) |
Hot
Back to products
Next product
Lithium, granular, 99% trace metals basis - Sigma-Aldrich
Price range: RM559.00 through RM1,625.00
Lithium nickel manganese cobalt oxide, electrode sheet, aluminum substrate, size 5 in. Ã 10 in. – Sigma-Aldrich
RM3,012.00
Brand:
Sigma-Aldrich
Synonyms
NMC
General Description
Lithium nickel manganese cobalt oxide (NMC) is a class of electrode material that can be used in the fabrication of lithium-ion batteries. Lithium-ion batteries consist of anode, cathode, and electrolyte with a charge-discharge cycle. These materials enable the formation of greener and sustainable batteries for electrical energy storage.
We are committed to bringing you Greener Alternative Products, which adhere to one or more of The 12 Principles of Greener Chemistry. This product has been enhanced for energy efficiency. Find details here.
Applications
NMC electrode sheet has a layered structure and can be used as an active cathode material. It can further be used in combination with single electrolyte interphase (SEI) for the fabrication of lithium-ion batteries.
Other Notes
Crystal Structure: Rhombohedral
Operating Conditions:
- Recommended maximum charge voltage: 4.4 V vs Li/Li+
- Recommended maximum charge current: 1C
- Recommended cut-off voltage for discharge: 2.7 V vs Li/Li+
- Recommended maximum discharge current: 1 C
- Recommended charge method: constant current – constant voltage
Description
Additional information
| Dimensions | 30 × 60 cm |
|---|---|
| Brand | Sigma |
| Estimated Delivery Time | 3-6 weeks |
