General Lab Equipment

Denaturing Gradient Gel Electrophoresis (DGGE) is an important technique used in the search for mutations and DNA polymorphisms critical in genetic disorders and cancers, and to understand genetic diversity among species. The new omniPAGE VS20WAVE-DGGE is a flexible system that can be fully customised to perform several different mutation detection techniques. The VS20WAVE-DGGE is a versatile single-unit solution for different single-base pair mutation detection methods. The newly designed VS20WAVE-DGGE is a complete system for DNA mutation analysis.

The omniPAGE range of Modular Vertical Gel Systems allow multiple electrophoresis techniques to be performed in the same unit. These systems include all modules and accessories required for Slab Gel Electrophoresis, 2-D Electrophoresis and Electroblotting. The central component is the omniPAGE Mini Vertical unit, Mini Wide Vertical Unit or omniPAGE Maxi Vertical unit.

Package includes:

• 1x omniPAGE Mini Wide Vertical Unit which includes: 2x4mm thick notched glass plates, 2x4mm thick plain glass plates with 1mm thick bonded spacers, 1x dummy plate, 2x combs (1mm thick, 24 samples), 1x casting base, silicone mat, cooling pack
• 1x Capillary Electrophoresis Module which includes: internal running module for tube gels, capillary tubes, blanking plugs, 2-D combs and spacers
• 1x Electroblotting Module comprising: internal electroblotting module, 4x compression cassettes for gel sizes up to 20x10cm and 6x fibre pads.

The omniPAGE range of Modular Vertical Gel Systems allow multiple electrophoresis techniques to be performed in the same unit. These systems include all modules and accessories required for Slab Gel Electrophoresis, 2-D Electrophoresis and Electroblotting. The central component is the omniPAGE Mini Vertical unit, Mini Wide Vertical Unit or omniPAGE Maxi Vertical unit. These include a rapid and intuitive casting system, enhanced and easy to set up cooling system and increased capacity to run up to four gels per run.

Package includes:

• 1x omniPAGE Mini Vertical Unit which includes: 2x2mm thick notched glass plates, 2x2mm thick plain glass plates with 1mm thick bonded spacers, 1x dummy plate, 2x combs (1mm thick 12 samples), 1x casting base, silicone mat, cooling pack
• 1x Capillary Electrophoresis Module which includes: internal running module for tube gels, capillary tubes, blanking plugs, 2-D combs and spacers
• 1x Electroblotting Module comprising: internal electroblotting module, 4x compression cassettes for gel sizes up to 10x10cm and 16x fibre pads.

The VS20 WAVE complete electrophoresis system provides a fully integrated solution using one universal gel tank and lid for vertical PAGE, tube gel IEF and electroblotting:

• Interchangeable modular inserts allow users to combine vertical PAGE with capillary gel IEF to perform 2-D electrophoresis, followed by western transfer for enhanced sensitivity
• Scale-up your discovery projects using a large format, high-resolution system
• Cooling supplied for temperature-sensitive separations and samples
• High-intensity blotting system available for rapid transfers

Package includes:

• 1x WAVE Maxi Vertical Unit which includes: PAGE insert, 2x4mm thick notched glass plates, 2x4mm thick plain glass plates with 1mm thick bonded spacers, 1x dummy plate, 2x combs (1mm thick 24 samples), 1x casting base, silicone mat, cooling coil
• 1x WAVE Standard Electroblotting Module which includes: WAVE Maxi Platinum Wire Blotting Insert, 4x compression cassettes and 18x fibre pads
• 1x WAVEDCI Capillary Electrophoresis Module which includes: WAVE Maxi Tube Gel Insert, 100x capillary tubes,10x blanking ports
• 1x WAVE IEF-KIT: 1 set of plain glass plates with bonded spacers, 0.6x20cm (w x h); and 2x 2-D combs with one 3.5mm marker lane and one 18cm preparatory well

The VS20 WAVE complete electrophoresis system provides a fully integrated solution using one universal gel tank and lid for vertical PAGE, tube gel IEF and electroblotting.

• Interchangeable modular inserts allow users to combine vertical PAGE with capillary gel IEF to perform 2-D electrophoresis, followed by western transfer for enhanced sensitivity
• Scale-up your discovery projects using a large format, high-resolution system
• Cooling supplied for temperature-sensitive separations and samples
• High-intensity blotting system available for rapid transfers

Package includes:

• 1x WAVE Maxi Vertical Unit which includes: PAGE insert, 2x4mm thick notched glass plates, 2x4mm thick plain glass plates with 1mm thick bonded spacers, 1x dummy plate, 2x combs (1mm thick 24 samples), 1x casting base, silicone mat, cooling coil
• 1x WAVE High Intensity Electroblotting Module which includes: WAVE Maxi Plate Electrode Blotting Insert, 1x compression cassette and 6x fibre pads
• 1x WAVEDCI Capillary Electrophoresis Module which includes: WAVE Maxi Tube Gel Insert, 100x capillary tubes,10x blanking ports
• 1x WAVE IEF-KIT: 1 set of plain glass plates with bonded spacers, 0.6x20cm (w x h); and 2x 2-D combs with one 3.5mm marker lane and one 18cm preparatory well

The redesigned VS20DGGETC temperature control unit combines buffer recirculation with a heat sensor and 1.4kW heating element to facilitate precise temperature control to within 0.02C, allowing the gel temperature to be set to the melting temperature (Tm) of the amplified DNA polymorphism or mutation of interest. Other benefits include; a conspicuous 4-digit 16mm LED panel to aid set-up, precise tuning to within 0.1C resolution, an operating set point, plus three adjustable pre-set temperature values, and stirred buffer circulation for temperature stability and uniformity.
